How can I create a background image with two pictures, a white line, and a blue background in Webflow? The current method I'm using with one big background image is not accurate in terms of size, scalability, and quality. Is there a better way to achieve this in Webflow? Thank you for your help.
TL;DR
- Build the layout in Webflow using separate image elements, a styled div for the white line, and a section with a blue background.
- Use Flex or Grid for alignment, apply responsive units and object-fit settings for scalability, and optionally use absolute positioning for custom layouts.
To create a composite background design (two images, a white line, and a blue background) with better scalability and image quality in Webflow, avoid using one combined image file. Instead, build the layout using Webflow elements and layers.
1. Use Webflow Elements Instead of a Single Image
- Instead of one background image, break the design into individual elements: image blocks, dividers (for lines), and background color.
- This allows for responsive control, better scaling, and reduced image distortion.
2. Create a Background Section
- Add a Section to the page.
- Set the background color of the section to your desired blue tone using the Backgrounds panel.
3. Add a Flex or Grid Layout
- Inside the section, add a Div Block and set it to display: flex (horizontal) or use Grid depending on layout precision.
- This lets you place the two images and the line side by side.
4. Add Individual Image Elements
- Drag in two Image elements inside the parent Div Block (left and right positions).
- Upload and assign the appropriate images to each.
5. Insert a Vertical White Line
- Between the two images, add another Div Block to serve as the line.
- Style it as follows:
- Width: 1–2px
- Background: White
- Height: 100% or desired size
- Add margins or padding as necessary to space it properly between the images.
6. Make it Responsive
- Use percent or viewport-based units (VW/VH) for widths/heights.
- Use object-fit: cover or contain on images if needed to preserve quality.
- Adjust layout settings for tablet and mobile breakpoints to maintain a responsive design.
7. Optional: Absolute Positioning for Creative Layouts
- If you'd prefer overlapping items or more creative positioning:
- Set the parent Div Block to position: relative.
- Set child images or the line to absolute or fixed positioning as needed.
- This gives you pixel-perfect control but requires careful responsiveness setup.
Summary
Instead of using a single large background image, build your layout in Webflow with individual images, a styled div for the white line, and a section with a blue background. This method ensures better scalability, image quality, and responsive control across all devices.
